PRODUCT | HYDROGRAPHIC SURVY

XBOAT-4100HS

USV / Echo Sounder / Autopilot

MSRP:€-/-

Part Number.:#G2001
  • KEY FEATURES
  • SPECS

KEY FEATURES


The XBOAT-4100HS is a professional unmanned surface vessel (USV). It features portable and propulsion, as well as high-capacity loads. The hull uses high-strength nautical materials and components. Easy to disassemble and transport. It can be used for sewage treatment in lakes, ports and small waters. The XBOAT-4100HS is also available with the optional TOSLON autopilot. Whether in autopilot or manual mode, the operator can monitor it via GPS positioning technology. The XBOAT-4100HS can be equipped with ADCP multi-beam sonar, dual-frequency sonar, RTK and other loads to achieve fast and economical measurement and rescue.

SPECS

Dimension
119*62.4*23CM (L*W*H)
Battery 1*14.8V 24AH Li-ion Battery
Battery Endurance
Up to 10km
Payload
35 kg
Motor Dual Brushless 12V DC Outdrives
Hull Material
HDPE
Weight of Base Boat
13 kg
Remote 2.4GHz, omni directional antenna
Remote Control Range
2 km
GPS customer specified: RTK/GNSS, DGPS
Transducer Multi-beam sonar; Single-beam sonar, Side scan sonar, ADCP
